Tensile Fabric Structure for Luxes Island Saddle Club - Chendu, China

  •

     Date Completed  June, 2016
     Location  Chendu, China
     Project Area  7000 square meters
     Membrane Material  PVDF
     Fabric Color  White
     Shape  Hypar, Cone
     Structure  Q235 Steel, Hot Dip Galvanized
     Warranty  20 Years
     Delivery Time  About 30 Days after confirm deposit
     Payment  T/T, LC
     Brand  BDiR
     Place of Origin  Shenzhen, China



  • INQUIRY NOW
Tensile Fabric Structure for Luxes Island Saddle Club - Chendu, China

Description

Equestrian is a particular outdoor sport different from others. It allows children to have more exposure to the outdoors and nature. In the process of training with the horse, they can also consciously cultivate love with animals.

Chengdu Wuhu Eco-City Equestrian Club is located in the Penghu Eco-City, with a 6000 square meters outdoor horse farm and a 5, 000 square meters indoor horse hall. It also has the largest 2, 200-meters grassland arc runway in Asia. Because of its excellent court and strength, the Dubai International Cup and the Chinese Equestrian Festival were held here.

The construction uses Chinese traditional materials, red bricks as main construction materials. In June 2016, BDiR cooperated with the project management team. Due to need coverage of a 45-meters-long equestrian event area, we chose a highly industrialized and lightweight fabric structure. It is transformed into an umbrella-shaped flying column structure, and umbrella-shaped flying column by the pull ring method. This is a formal design based on structural logic. The artistry of the stretched fabric structure complements the traditional red brick architecture and is highly visually appealing.

The design and installation difficulty of this project has reached an unprecedented height. Tensile canvas awning structure of the racecourse is composed of the surrounding columns + the centre column. The maximum span reaches 108 meters.

It’s a magical piece. After the membrane tensioned, looks like a bird,  wants to fly higher, but is firmly held by the cable that protrudes from the earth.

There is a children’s entertainment area next to the racecourse. We used the terrain difference between the stables and the road to build playground commercial metal canopy for children.


Specifications

    • √. Large Span: Tensile Structures can create an expansive covered area, exceed to 200m.

    • √. Unique Design: Tensile fabric Structure gives architects, designers, and engineers the opportunity to experiment with form and create visually exciting and iconic structures.

    • √. Various Shape: Changeful supporting structure can make lots of different shapes of tensioned structure with flexible membrane.

    • √. Cost-effective: About 1/3 to 1/2 lower than conventional structures on costs.

    • √. Easy to Install: Faster and more cost-effective in comparison to traditional construction projects.

    • √. Weatherproof: Durable and designed to withstand even the most severe weather conditions. Provide protection from both the rain and sun.

    • √. Excellent Durability: Fabric tensile Structure is characterized by durability and longevity, can be built in different areas around the world, from the frigid arctic pole to the scorching desert heat.

    • √. ECO Friendly: Have high sun reflectivity and low solar absorption. As a result, less energy is used in the building, ultimately reducing the cost of electricity.

    • √. Low maintenance Needs: Tensile membrane Structures require minimal maintenance for clients, whether use of PVC, PVDF, PTFE or ETFE.

    • √. Outstanding Natural Daylighting: Membrane is translucent, In daylight, tension structures could offer rich soft diffused naturally daylight space, and at night, artificial lighting can make it bright and colorful.



Design & Model



    Tensile Fabric Structure for Luxes Island Saddle Club Design

    Tensile Fabric Structure for Luxes Island Saddle Club Model

Installation

       Step 1: Design

       BDiR use the latest tensile structural design software to produce
       detailed tensile structural designs.


       Including:
       BIM model design (building information modeling),
       finding and load analysis,  integrated building design,
       joint force analysis, membrane cutting analysis,
       construction process simulation, numerical wind tunnel simulation.
    Step 2: Membrane Fabrication

    Membrane fabrication plays an important role in the tensile structure.

    There are many fabrics (PVC, PVDF, PTFE, ETFE) in the market, they come from all over the world, they have different characteristics and prices, different welding or joining techniques. We will make the best choices from structural design, project location and our customer budget.
      Step 3. Steel Fabrication

      Tensile structure are made of steel structural members that are welded
      and painted in our factory.


      We will conduct the following procedures with high standards:
      Paint thickness detection, ultrasonic testing,
      magnetic particle testing,
    high-strength bolt torque testing,
      cable pre-tensioning, rust removal ,

      pre-assembly inspection, painting, etc.

    Step 4: Cable Fabrication

    Cable and hardware fittings are procured from the most reliable and certified vendors of the industry in compliance with the international quality standards.

    Cable fabrication are proceed under guidance of our skilled and experienced experts.
      Step 5: Installation

      The installation of the tension structure is critical to the overall success
      of the project.


      We will provide on site installation service. Our project manager will work
      with the client to coordinate the structure installation on site.  Including
      steel structure installation, membrane lifting and measure tension. If you
      prefer self-installation, we'll send you detailed instructions so it can be
      easily installed.


    Step 6: The Future

    Our service will not end at the time of delivery and installation!

    Because we only use the highest quality membrane materials and steel frames, cables and parts. You can rest assured that your new tensile structure is built to last. Besides, Tensile structure does not require much maintenance and we offer a up to 35 year warranty.
